PA11 Nylon single wall corrugated pipe machine for car

Short Description:

  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Product Detail

    Product Tags

    PVC spiral steel wire hose extrusion line

    asbsb (1)

    The Single and Double Wall Corrugated Pipe Extrusion Machine for Electrical Use are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.

    Single and Double Wall Corrugated Pipe Extrusion Machine for Electrical Use developed by our company adopts gears to run modules and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe wall. These corrugated pipes are especially used in wires conduit

    We can design the speed with 10-12m/min ,18-20m/min and 25-30m/min with the customer need , contact way : Ms lily , mobile 008615806538967

    asbsb (2)
    asbsb (3)
    asbsb (4)
    PA11 single wall corrugated pipe line1.SJ45 single screw extruder

    2.Auto loader and dryer

    3.Die head

    4.Air pressure clock

    5.High speed calibration table

    6.Set length cutter machine

    7.Mould design according to sample

    ( 130mm & 170mm )

    1 set

    Product application:conduits for wire,washing machinery pipe ,basin shrinking pipe ,medical tube etc .

    asbsb (5)

    Die head & forming machine & forming mould

    asbsb (6)
    Die head


    1 Die head material 40Cr
    2 Inner structure Spiral type
    3 Melt pressure meter Equip with a pressure meter to monitor the melt pressure in the die head
    Forming machine & forming mould


    1 Material of forming mould 40Cr, nitrogen treated
    2 Forming mould 1 set
    3 Quantity of mould block 50 pairs ( depends on sample )
    4 Forming machine type Horizontal type
    5 Forming mould moving way Circle
    6 Drive motor power 4kw
    7 Inverter Holip
    8 Cooling way Air cooling
    9 Power of blower 180w×3
    asbsb (7)
    asbsb (8)
    asbsb (9)
    asbsb (10)

    asbsb (11) asbsb (12) asbsb (13) asbsb (14)
